With incredible video quality, ease of use, and powerful networking tools, Revo Ultra is the very best that Revo has to offer. The Revo Ultra’s superb video quality is based on IP technology. The “RU162BNDL-4” is a complete plug and play HD surveillance system with 16 CH 4K NVR, 4TB & 12x 4MP HD Indoor/outdoor Audio Capable Cameras. The REVO ULTRA NVR is powerful featuring state of the art H.265 Compression, up to 12 Megapixel Recording and 4K video output. The Cameras feature IR anti reflection glass, professional grade “OSRAM” LEDs, massive 2K Sensors, double the resolution of standard 1080p. The “OSRAM” LEDs strongly illuminate the scene up to an unprecedented 100’ in total darkness. All 8 cameras come equipped with a built-in microphone for audio streaming and recording. The cameras are built for the outdoors capable of handling temperatures as hot as 140F and as cold as -40F. The “RUCB36-1A” bullet camera features a 3.6mm fixed lens for wide field of view coverage. The “RUCT2812-1” Turret Camera features 4X optical Zoom and a 2.8 to 12mm automatic lens allows convenient adjustment of the field of view of the camera. The polished look and intuitive feel of the Ultra’s interface is a joy for everyday use whether you’re using the NVR itself, the Mobile App, Computer Software or Browser.
NDAA Compliant
Ultra HD Audio Capable 16 CH. 4TB NVR Surveillance System With 12 4 Megapixel Cameras
SKU: RU162BNDL-4
$1,488.36
-10%
FREE delivery
Core features
- 16 Ch. 4K IP NVR with 16 RJ45 PoE Ports
- 4 TB pre-installed HDD
- 4MP Motorized Varifocal Turret Cameras with built-in Microphone (4)
- 4 MP Fixed Lens Bullet Camera with built-in Microphone (8)
- 1-ch VGA, 1-ch HDMI at up to 4K(3840×2160) resolution
- H.265 Compression
- Supports easy firmware upgrade via Cloud
- 100’ CAT5e Cable (12)
- Two-Step Smartphone View Setup via “REVO ULTRA” app – iPhone and Android
- Myrevocloud.com – Access your Ultra NVR from virtually any Internet Explorer browser
Delivery & Returns
For Same Day Freight, order by 2PM CT and receive your package. Returns are accepted within 30 days of product delivery, provided they are undamaged and in the original packaging.
Additional information
| Weight | 30.0 lbs |
|---|---|
| Open Box: No selection | No |
| Storage: No selection | 4 TB, 5 TB, 6 TB, 7 TB, 8 TB |
| Upc: No selection | 045924598455 |
| Type: No selection | ip |
| Audio Recording: No selection | Yes |
| Disk Space: No selection | 4 TB |
Technical Specifications
RUCT2812-1 4MP WDR (Motorized) VF Eyeball Network IR Camera
| Camera | |
|---|---|
| Sensor | 1/3″, progressive scan, 4.0 megapixel, CMOS |
| Lens | 2.7~12 mm,AF automatic focusing and motorized zoom lens |
| Angle of view(H) | 91.0°~27.0° |
| Shutter | Auto/Manual, 1/6~1/100000 s |
| Min. Illumination | Colour: 0.01 Lux (F1.4, AGC ON) 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52dB |
| IR Range | Up to 30m (98 ft) IR range |
| Defog | Digital Defog |
| WDR | 120dB |
| Video | |
|---|---|
| Video Compression | Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream:4MP (2592×1520): Max. 20 fps，4MP (2560×1440): Max. 25 fps，3MP (2048×1520): Max. 30 fps; Sub Stream:2MP (1920×1080): Max. 30 fps; Third Stream:D1(720×576) : Max. 30fps |
| HLC | Supported |
| BLC | Supported |
| 9:16 Corridor Mode | Supported |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 8 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| Smart | |
|---|---|
| Behavior Detection | Intrusion, cross line, motion detection |
| Intelligent Identification | Face detection, Defocus, Scene Change |
| Statistical Analysis | People counting |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio | |
|---|---|
| Audio Compression | G.711 |
| Suppression | Supported |
| Sampling Rate | 8 KHZ |
| Storage | |
|---|---|
| Edge Storage | Micro SD, up to 128 GB |
| Network Storage | ANR |
| Network | |
|---|---|
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP |
| Compatible Integration | ONVIF(Profile S, Profile G), API |
| Interface | |
|---|---|
| Built-in Mic | Supported |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| General | |
|---|---|
| Power | 12 V DC±25%, PoE (IEEE802.3 af) Power consumption: Max 8.16W |
| Dimensions (Ø x H) | Φ129 x 110 mm (Ø5.08” x 4.3”) |
| Weight | 0.67 kg (1.48lb) |
| Working Environment | -40°C ~ +60°C (-40°F ~ 140°F), Humidity:10%~95% RH(non-condensing) |
| Ingress Protection | IP67 |
| Reset Button | Supported |
RUCB36-1 4MP IR Bullet Camera
| Camera | |
|---|---|
| Sensor | 1/3″, 4.0 megapixel, progressive scan, CMOS |
| Lens | 3.6mm@F1.8 Angle of view(H): 90.5° |
| Shutter | Auto/Manual, 1/6~1/8000 s |
| Min. Illumination | Color: 0.02 Lux (F1.8, AGC ON) 0 Lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| IR Range | Up to 30m (98 ft) IR range |
| S/N | >55dB |
| WDR | 120dB |
| Noise Reduction | 2D/3D |
| Video | |
|---|---|
| Max. Resolution | 2592×1520 |
| Video Compression | H.264/MJPEG |
| Frame Rate | 4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps 3MP (2048×1520): Max. 30 fps; 1080P (1920×1080): Max. 30 fps |
| Video Streaming | Triple |
| 9:16 Corridor Mode | Supported |
| ROI | Supported |
| OSD | Up to 8 OSDs |
| Motion Detection | Up to 2 areas |
| Privacy Mask | Up to 4 areas |
| Network | |
|---|---|
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP, HTTP |
| Compatible Integration | API |
| Interface | |
|---|---|
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| General | |
|---|---|
| Power | 12 V DC, or PoE (IEEE802.3 af 2.0 W (6.4 W with IR on) |
| Dimensions (L × W × H) | 157.3 × 62.4 ×63 mm (6.2” × 2.5” × 2.5”) |
| Weight | 0.45 kg (0.99 lb) |
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing) |
| Ingress Protection | IP66 |
DVR-4575 8 Channel Digital Video Recorder
| Video | |
|---|---|
| Video Input | 8 Channels |
| Video Outputs | VGA, HDMI |
| Display Resolution | Up to 1080p |
| Audio | |
|---|---|
| Audio Input | 1 x RCA |
| Audio Outputs | 1 x RCA |
| Recording | |
|---|---|
| Recording Resolution | Up to 3MP |
| Hard Drive Support | Includes 1TB SATA HDD(supports up to 4TB) |
| Connection | |
|---|---|
| Network Interface | RJ45 x 1 |
| USB Interface | USB 2.0 x 2, USB 3.0 x 1 |
| Software | |
|---|---|
| Computer Operating System | Windows, Mac OS |
| Internet Viewing | HomeSafe View App |
| Handheld Device Supported | iOS, Android, 3G/4G Smartphones & Tablets |
| General | |
|---|---|
| Dimensions (WxDxH) | 9.05″ x 8.3″ x 1.9″ 230mm x 210mm x 47mm |
Disclaimer
Specs and design can change without previous notice
